| 規格 | 內徑 | 外徑 | 成品小內徑 | 成品外徑 | 標配 | 工作壓力 | 爆破壓力 | 彎曲半徑 | 重量 |
| 型號 | (mm) | (mm) | (mm) | (mm) | 連接方式 | (Mpa) | (Mpa) | (mm) | (Kg/m) |
| LT-110-3 | 3 | 7 | 1.6 | 8.2 | M8M5 | 110 | 275 | 60 | 0.07 |
| LT-120-4 | 4 | 7.7 | 2.2 | 10.5 | M8X1.25 | 120 | 300 | 75 | 0.1 |
| LT-140-4 | 4 | 10 | 2.1 | 15 | 1/4NPT | 140 | 350 | 55 | 0.16 |
| LT-150-4 | 4 | 7.9 | 2 | 10.5 | M8X1.25 | 150 | 375 | 75 | 0.11 |
| LT-220-4 | 4 | 10.4 | 1.4 | 15 | 3/8LH | 220 | 550 | 100 | 0.21 |
| LT-280-5 | 4 | 12 | 1.3 | 17 | 3/8LH | 280 | 700 | 140 | 0.39 |
| LT-280-5 | 5 | 13.2 | 2.4 | 19.5 | 3/8LH | 280 | 700 | 200 | 0.47 |
| LT-400-5 | 5 | 15 | 2.2 | 19.6 | 3/8LH | 400 | 800 | 200 | 0.66 |
| LT-110-6 | 6 | 11.5 | 3.7 | 15 | M10X1 | 110 | 275 | 110 | 0.2 |
| LT-164-6 | 6 | 12.5 | 3.5 | 17.5 | M10X1 | 164 | 410 | 155 | 0.33 |
| LT-90-8 | 8 | 13.3 | 5 | 18 | 9/16LH | 90 | 225 | 120 | 0.25 |
| LT-150-8 | 8 | 15.1 | 5 | 20 | 9/16LH | 150 | 375 | 175 | 0.44 |
| LT-250-8 | 8 | 17.2 | 3.7 | 23 | 9/16LH | 250 | 625 | 200 | 0.83 |
| LT-280-8 | 8 | 17.3 | 3.7 | 23 | 9/16LH | 280 | 700 | 230 | 0.9 |
| LT-300-8 | 8 | 19.5 | 3.5 | 24 | 9/16LH | 300 | 700 | 250 | 1.1 |
| LT-320-8 | 7.8 | 19.6 | 3.4 | 24 | 9/16LH | 320 | 800 | 280 | 1.1 |
| LT-160-10 | 10 | 21.6 | 5.5 | 34 | M24E0 | 160 | 400 | 95 | 0.94 |
| LT-110-13 | 13 | 23 | 7.3 | 34 | M24E0 | 110 | 275 | 100 | 0.8 |
| LT-140-13 | 13 | 25 | 7.3 | 34 | M24E0 | 140 | 350 | 110 | 1.19 |
| LT-180-13 | 13 | 24.5 | 7 | 36.5 | M24E0 | 180 | 450 | 290 | 1.36 |
| LT-200-13 | 13 | 27 | 7 | 31.5 | M20×1.5LH | 200 | 500 | 300 | 1.85 |
| LT-250-13 | 12.7 | 29.8 | 7 | 34.5 | M20×1.5LH | 250 | 625 | 350 | 2.5 |
| LT-300-13 | 13 | 29.9 | 7 | 34.2 | M20×1.5LH | 300 | 625 | 350 | 2.5 |
| LT-140-20 | 20 | 33 | 12.3 | 53.5 | M36E0 | 140 | 350 | 350 | 2.1 |
| LT-160-20 | 20 | 33.7 | 12.3 | 53.5 | M36E0 | 160 | 400 | 350 | 2.28 |
